Description
Shoayer Part Number | SY1180-3-28/19 | ||
Rated Voltage | 300V | ||
Rated Temperature | ﹣80℃~﹢200℃ | ||
Conductor | Material | Nickel plated copper | |
AWG | 28AWG | ||
Composition | No.*AWG | 19/40AWG | |
No.* mm | 19/0.08mm | ||
Diameter | 0.40mm | ||
Insulation | Material | PTFE (Poly tetra fluoro ethylene ) | |
Thickness | 0.33mm | ||
Outer Diameter (mm) |
1.06±0.05mm | ||
Color | Optional | ||
Package | 610m/roll | ||
Estimate weight | 2.61km/kg | ||
Rated current | 0.86A | ||
Max conductor resistance DC 20℃ | 188.57Ω/km |
