SY1199-2-24/1
1199 PTFE 600V 200℃ High Tempereture Wire
Description
Description
| Shoayer Part Number | SY1199-2-24/1 | ||
| Rated Voltage | 600V | ||
| Rated Temperature | ﹣80℃～﹢200℃ | ||
| Conductor | Material | Silver plated copper | |
| AWG | 24AWG | ||
| Composition | No.*AWG | 1/24AWG | |
| No.* mm | 1/0.51mm | ||
| Diameter | 0.51mm | ||
| Insulation | Material | PTFE (Poly tetra fluoro ethylene ) | |
| Thickness | 0.51mm | ||
| Outer Diameter (mm) |
1.53±0.05mm | ||
| Color | Optional | ||
| Package | 610m/roll | ||
| Estimate weight | 5.61km/kg | ||
| Rated current | 1.98A | ||
| Max conductor resistance DC 20℃ | 82Ω/km | ||
