SY1332-1-24/19
1332 300V 200℃ FEP high temperature wire
Description
Description
| Shoayer Part Number | SY1332-1-24/19 | ||
| Rated Voltage | 300V | ||
| Rated Temperature | ﹣80℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| AWG | 24AWG | ||
| Composition | No.*AWG | 19/36AWG | |
| No.* mm | 19/0.127mm | ||
| Diameter | 0.61mm | ||
| Insulation | Material | FEP (Fluorinated ethylene propylene) | |
| Thickness | 0.33mm | ||
| Outer Diameter (mm) |
1.27±0.1mm | ||
| Color | Optional | ||
| Package | 610m/roll | ||
| Estimate weight | 4.50km/kg | ||
| Rated current | 2.17A | ||
| Max conductor resistance DC 20℃ | 75Ω/km | ||
