SY2464-1-10×24/11
2464 300V 80℃ Multi-core PVC Cable
Description
Description
| Shoayer Part Number | SY2464-1-10×24/11 | ||
| Rated Voltage | 300V | ||
| Rated Temperature | ﹣40℃～﹢80℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 10x24AWG | ||
| Composition (No.* mm) | 11/0.16mm | ||
| Insulation | Material | PVC (Polyvinyl chloride) | |
| Thickness | 0.25mm | ||
| Diameter | 1.10mm | ||
| Jacket | Material | PVC (Polyvinyl chloride) | |
| Thickness | 0.76mm | ||
| Outer Diameter (mm) | 6.50±0.1mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Max conductor resistance DC 20℃ | 94.2Ω/km | ||
