Description
| Shoayer Part Number | SYAFPF-1-4×2.5/19 | ||
| Rated Voltage | 300/500V | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 4×2.5mm² | ||
| Composition (No.* mm) | 19/0.41mm | ||
| Diameter | 2.00mm | ||
| Insulation | Material | FEP(Fluorinated ethylene-propylene) | |
| Thickness | 0.40mm | ||
| Diameter | 2.80mm | ||
| Shielded | Tinner plated copper | ||
| Jacket | Material | FEP(Fluorinated ethylene-propylene) | |
| Thickness | 0.40mm | ||
| Average Outer Diameter (mm) | 8.20±0.3mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Max conductor resistance DC 20℃ | 6.86Ω/km | ||
