SYAFPF-1-8×0.12/7

AFPF 300V 200℃ Multi-core Teflon Shielded Cable

Description

Shoayer Part Number		SYAFPF-1-8×0.12/7
Rated Voltage		300/500V
Rated Temperature		﹣60℃～﹢200℃
Conductor	Material	Tinner plated copper
	SQMM	8×0.12mm²
	Composition (No.* mm)	7/0.15mm
	Diameter	0.45mm
Insulation	Material	FEP(Fluorinated ethylene-propylene)
	Thickness	0.20mm
	Diameter	0.85mm
Shielded		Tinner plated copper
Jacket	Material	FEP(Fluorinated ethylene-propylene)
	Thickness	0.30mm
Average Outer Diameter (mm)		3.90±0.1mm
Color		Optional
Package		610m/roll
Max conductor resistance DC 20℃		150Ω/km
