SYAGG-1-2.5/49-A1KV
AGG 1KVAC 200℃ Silicone Rubber High Voltage Wire
Description
Description
| Shoayer Part Number | SYAGG-1-2.5/49-A1KV | ||
| Rated Voltage | 1KVAC | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 2.5mm² | ||
| Composition (No.* mm) | 49/0.254mm | ||
| Diameter | 2.00mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 1.20mm | ||
| Outer Diameter (mm) |
4.40±0.2mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Estimate weight | 56km/kg | ||
| Max conductor resistance DC 20℃ | 8.21Ω/km | ||
