SYFF46-1-0.35/7

FF46-1 600V 200℃ Tinned Copper Teflon Wire

Category: FF46

Description

Shoayer Part Number		SYFF46-1-0.35/7
Rated Voltage		600V
Rated Temperature		﹣80℃～﹢200℃
Conductor	Material	Tinner plated copper
	SQMM	0.35mm²
	Composition (No.* mm)	7/0.254mm
	Diameter	0.76mm
Insulation	Material	FEP (Fluorinated ethylene propylene)
	Thickness	0.25mm
Outer Diameter (mm)		1.26±0.05mm
Color		Optional
Package		610m/Roll
Estimate weight		5.08km/kg
Max conductor resistance DC 20℃		50.77Ω/km
