SYGN50002-3-6.0/84

GN500-02 300V 450℃ Fire Resistant Wire

Category: GN500-02

Description

Shoayer Part Number		SYGN50002-3-6.0/84
Rated Voltage		300/500V
Rated Temperature		﹣60℃～﹢450℃
Conductor	Material	Nickel plated copper
	SQMM	6mm²
	Composition (No.* mm)	84/0.30mm
	Diameter	3.15mm
Insulation	Material	Fluorine mica tape + Fiberglass braid
	Thickness	0.80mm
Outer Diameter(mm)		5.50±0.5mm
Color		Optional
Package		100m/roll
Max conductor resistance DC 20℃		3.03Ω/km
