Description
Shoayer Part Number | SYM16878/13-1-28/1 | ||
Rated Voltage | 250V | ||
Rated Temperature | ﹣55℃~﹢200℃ | ||
Conductor | Material | Tinner plated copper | |
AWG | 28AWG | ||
Composition | No.*AWG | 1/28AWG | |
No.* mm | 1/0.32mm | ||
Diameter | 0.32mm | ||
Insulation | Material | FEP (Fluorinated ethylene propylene) | |
Thickness | 0.15mm | ||
Outer Diameter (mm) |
0.62±0.05mm | ||
Color | Optional | ||
Package | 610m/roll | ||
Estimate weight | 1.24km/kg | ||
Rated current | 0.318A | ||
Max conductor resistance DC 20℃ | 214Ω/km |
