SYM22759/16-1-10/37
MIL-W-22759/16 600V 150℃ ETFE High Temperature Wire
Description
Description
| Shoayer Part Number | SYM22759/16-1-10/37 | ||
| Rated Voltage | 600V | ||
| Rated Temperature | 150℃ | ||
| Conductor | Material | Tinner plated copper | |
| AWG | 10AWG | ||
| Composition | No.*AWG | 37/26AWG | |
| No.* mm | 37/0.40mm | ||
| Diameter | Min. | 0.106mm | |
| Max. | 0.112mm | ||
| Insulation | Material | ETFE (ethylene-tetrafluoroethylene) | |
| Thickness | 0.254mm | ||
| Outer Diameter (mm) |
0.139±0.003mm | ||
| Color | Optional | ||
| Estimate weight | 35.1km/kg | ||
| Max conductor resistance DC 20℃ | 1.26Ω/km | ||
