SYRV-0-16/126
RV PVC 450V 70℃ Household wire
Description
Description
| Shoayer Part Number | SYRV-0-16/126 | |
| Rated Voltage | 450/750V | |
| Rated Temperature | ﹣20℃～﹢70℃ | |
| Conductor | Material | Bare copper |
| SQMM | 16mm² | |
| Composition (No.* mm) | 126/0.40mm | |
| Diameter | 5.20mm | |
| Insulation | Material | PVC (Polyvinyl chloride) |
| Thickness | 1.00mm | |
| Outer Diameter (mm) |
7.20±0.1mm | |
| Color | Optional | |
| Package | 100m/Roll | |
| Estimate weight | 173.13km/kg | |
| Max conductor resistance DC 20℃ | 1.15Ω/km | |
