SYRVVP-0-8×0.2/12
RVVP 300V Multi-core PVC Shield Cable
Description
Description
| Shoayer Part Number | SYRVVP-0-8×0.2/12 | ||
| Rated Voltage | 300V | ||
| Rated Temperature | ﹣45℃～﹢70℃ | ||
| Conductor | Material | Bare copper | |
| SQMM | 8×0.2mm² | ||
| Composition (No.* mm) | 12/0.15mm | ||
| Insulation | Material | PVC (Polyvinyl chloride) | |
| Thickness | 0.40mm | ||
| Diameter | 1.45mm | ||
| Shield | Material | Tinner plated copper | |
| Size | 16/7/0.09 | ||
| Jacket | Material | PVC (Polyvinyl chloride) | |
| Thickness | 0.60mm | ||
| Outer Diameter (mm) | 7.00±0.1mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Max conductor resistance DC 20℃ | 84.93Ω/km | ||
