SYYGZF-1-19×0.75/19
YGZF 300V 200℃ FEP Insulation Silicone Rubber Jacket Cable
Description
Description
| Shoayer Part Number | SYYGZF-1-19×0.75/19 | ||
| Rated Voltage | 300/500V | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 19×0.75mm² | ||
| Composition (No.* mm) | 19/0.23mm | ||
| Diameter | 1.20mm | ||
| Insulation | Material | FEP (Fluorinated ethylene propylene) | |
| Thickness | 0.25mm | ||
| Diameter | 1.70mm | ||
| Jacket | Material | Silicone rubber | |
| Thickness | 1.80mm | ||
| Outer Diameter (mm) | 12.10±1mm | ||
| Color | Optional | ||
| Package | 50m/roll | ||
| Max conductor resistance DC 20℃ | 24.6Ω/km | ||
