SYYGZP-1-5×0.75/42
YGZP 300V 200℃ Multi-core Silicone Rubber Shielded Cable
Description
Description
| Shoayer Part Number | SYYGZP-1-5×0.75/42 | ||
| Rated Voltage | 300/500V | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 5×0.75mm² | ||
| Composition (No.* mm) | 42/0.15mm | ||
| Diameter | 1.20mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 0.60mm | ||
| Diameter | 2.40mm | ||
| Shieded | Tinner plated copper | ||
| Jacket | Material | Silicone rubber | |
| Thickness | 1.50mm | ||
| Average Outer Diameter (mm) | 10.0±1mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Max conductor resistance DC 20℃ | 26.7Ω/km | ||
