SYYHF-0-120/3072

YHF PVC 200V 105℃ Welding Cable

Categories: YHF, YHF Tag: car battery wire

Description

Shoayer Part Number			SYYHF-0-120/3072
Rated Voltage			200V
Rated Temperature			﹣30℃～﹢105℃
Conductor	Material		Flexible bare annealed copper
	SQMM		120mm²
	Composition	No.*AWG	3072/32AWG
		No.* mm	3072/0.20mm
	Diameter		15.1mm
Insulation	Material		PVC (Polyvinyl chloride)
	Thickness		2.8mm
Outer Diameter (mm)		Min.	19.0±0.5mm
		Max.	24.0±0.5mm
Color			Red, Black, Orange
Package			50m/roll
Estimate weight			1083.42km/kg
Max conductor resistance DC 20℃			0.161Ω/km
