SYYHF-0-70/2220

YHF PVC 200V 105℃ Welding Cable

Categories: YHF, YHF Tag: terminal battery cable

Description

Shoayer Part Number			SYYHF-0-70/2220
Rated Voltage			200V
Rated Temperature			﹣30℃～﹢105℃
Conductor	Material		Flexible bare annealed copper
	SQMM		70mm²
	Composition	No.*AWG	2220/32AWG
		No.* mm	2220/0.20mm
	Diameter		11.9mm
Insulation	Material		PVC (Polyvinyl chloride)
	Thickness		2.4mm
Outer Diameter (mm)		Min.	15.5±0.5mm
		Max.	19.5±0.5mm
Color			Red, Black, Orange
Package			50m/roll
Estimate weight			784.40km/kg
Max conductor resistance DC 20℃			0.272Ω/km
