SY10086-1-12/19
10086 600V 200℃ ETFE high temperature wire
Description
Description
| Shoayer Part Number | SY10086-1-12/19 | |
| Rated Voltage | 600V | |
| Rated Temperature | ﹣100℃～﹢200℃ | |
| Conductor | Material | Tinner plated copper |
| AWG | 12AWG | |
| Composition (No.* mm) | 19/0.47mm | |
| Diameter | 2.35mm | |
| Insulation | Material | ETFE (Ethyl tetra fluoro ethylene) |
| Thickness | 0.38mm | |
| Outer Diameter (mm) | 3.10±0.1mm | |
| Color | Optional | |
| Package | 305m/coil | |
| Estimate weight | 39.1km/kg | |
| Rated Current | 28A | |
| Max. Conductor Resiatence at DC20℃ | 5.64Ω/km | |
