HomeTeflon wireETFE wire10086 SY10086-1-(3/0)/133
Click to enlarge

SY10086-1-(3/0)/133

Rated 5.00 out of 5 based on 1 customer rating
5.0 ( excellent Supplier)

10086 600V 200℃ ETFE high temperature wire

Share
  • Description
  • Get An Instant Quote
Description

Description

Shoayer Part Number SY10086-1-(3/0)/133
Rated Voltage 600V
Rated Temperature ﹣100℃~﹢200℃
Conductor Material Tinner plated copper
AWG 3/0AWG
Composition (No.* mm) 133/0.90mm
Diameter 13.9mm
Insulation Material ETFE (Ethyl tetra fluoro ethylene)
Thickness 1.15mm
Outer Diameter (mm) 16.20±1mm
Color Optional
Package 50m/coil
Estimate weight 1030km/kg
Rated Current 255A
Max. Conductor Resiatence at DC20℃ 0.22Ω/km

Get An Instant Quote
