SYAFR250-0-0.06/12-125V

AFR250 PTFE 125V 250℃ High Tempereture Wire

Category: AFR250

Description

Shoayer Part Number		SYAFR250-0-0.06/12-125V
Rated Voltage		125V
Rated Temperature		﹣60℃～﹢250℃
Conductor	Material	Bare copper
	AWG	0.05mm²
	Composition (No.* mm)	12/0.08mm
	Diameter	0.30mm
Insulation	Material	PTFE (Poly tetra fluoro ethylene)
	Thickness	0.10mm
Outer Diameter (mm)		0.60±0.05mm
Color		Optional
Package		1500m/reel
Estimate weight		0.85km/kg
Rated Current		0.54A
Max. Conductor Resiatence at DC20℃		330Ω/km
