SYAFR250-2-0.035/7-600V

AFR250 PTFE 600V 250℃ High Tempereture Wire

Description

Shoayer Part Number		SYAFR250-2-0.035/7-600V
Rated Voltage		600V
Rated Temperature		﹣60℃～﹢250℃
Conductor	Material	Silver plated copper
	AWG	0.035mm²
	Composition (No.* mm)	7/0.08mm
	Diameter	0.25mm
Insulation	Material	PTFE (Poly tetra fluoro ethylene)
	Thickness	0.25mm
Outer Diameter (mm)		0.80±0.05mm
Color		Optional
Package		1500m/reel
Estimate weight		1.25km/kg
Rated Current		0.32A
Max. Conductor Resiatence at DC20℃		525Ω/km
