SYAFR250-3-0.1/21-300V

AFR250 PTFE 300V 250℃ High Tempereture Wire

Description

Shoayer Part Number		SYAFR250-3-0.1/21-300V
Rated Voltage		300V
Rated Temperature		﹣60℃～﹢250℃
Conductor	Material	Nickel plated copper
	AWG	0.1mm²
	Composition (No.* mm)	21/0.08mm
	Diameter	0.45mm
Insulation	Material	PTFE (Poly tetra fluoro ethylene)
	Thickness	0.15mm
Outer Diameter (mm)		0.75±0.05mm
Color		Optional
Package		1000m/reel
Estimate weight		1.6km/kg
Rated Current		0.95A
Max. Conductor Resiatence at DC20℃		188Ω/km
