SYAGCR-1-20/100
AGCR 300V 200℃ Super Flexible Silicone Wire
Description
Description
| Shoayer Part Number | SYAGCR-1-20/100 | ||
| Rated Voltage | 300/500V | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| AWG | 20AWG | ||
| Composition | No.*AWG | 100/40AWG | |
| No.* mm | 100/0.08mm | ||
| Diameter | 0.92mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 0.50mm | ||
| Outer Diameter (mm) |
1.92±0.1mm | ||
| Color | Optional | ||
| Package | 610m/roll | ||
| Estimate weight | 7.80km/kg | ||
| Rated current | 10A | ||
| Max conductor resistance DC 20℃ | 34.48Ω/km | ||
