SYAGG-1-1.0/32-D10KV
AGG 10KVDC 200℃ Silicone Rubber High Voltage Wire
Description
Description
| Shoayer Part Number | SYAGG-1-1.0/32-D10KV | ||
| Rated Voltage | 10KVDC | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 1mm² | ||
| Composition (No.* mm) | 32/0.20mm | ||
| Diameter | 1.40mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 1.50mm | ||
| Outer Diameter (mm) | 4.40±0.1mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Estimate weight | 27km/kg | ||
| Max conductor resistance DC 20℃ | 20Ω/km | ||
