SYAGG-1-10.0/84-A35KV
AGG 35KVAC 200℃ Silicone Rubber High Voltage Wire
Description
Description
| Shoayer Part Number | SYAGG-1-10.0/84-A35KV | ||
| Rated Voltage | 35KVAC | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 10mm² | ||
| Composition (No.* mm) | 84/0.40mm | ||
| Diameter | 4.20mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 7.40mm | ||
| Outer Diameter (mm) | 19.0±1mm | ||
| Color | Optional | ||
| Package | 50m/roll | ||
| Estimate weight | 448km/kg | ||
| Max conductor resistance DC 20℃ | 1.95Ω/km | ||
