SYAGG-1-10.0/84-A6KV
AGG 6KVAC 200℃ Silicone Rubber High Voltage Wire
Description
Description
| Shoayer Part Number | SYAGG-1-10.0/84-A6KV | ||
| Rated Voltage | 6KVAC | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 10mm² | ||
| Composition (No.* mm) | 84/0.40mm | ||
| Diameter | 4.20mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 3.40mm | ||
| Outer Diameter (mm) |
11.0±0.5mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Estimate weight | 202km/kg | ||
| Max conductor resistance DC 20℃ | 1.95Ω/km | ||
