SYAGG-1-150/760-A1KV
AGG 1KVAC 200℃ Silicone Rubber High Voltage Wire
Description
Description
| Shoayer Part Number | SYAGG-1-150/760-A1KV | ||
| Rated Voltage | 1KVAC | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 150mm² | ||
| Composition (No.* mm) | 760/0.50mm | ||
| Diameter | 16.0mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 3.70mm | ||
| Outer Diameter (mm) |
23.40±1mm | ||
| Color | Optional | ||
| Package | 50m/roll | ||
| Estimate weight | 1655km/kg | ||
| Max conductor resistance DC 20℃ | 0.132Ω/km | ||
