Description
| Shoayer Part Number | SYAGG-1-6.0/84-D10KV | ||
| Rated Voltage | 10KVDC | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 6mm² | ||
| Composition (No.* mm) | 84/0.30mm | ||
| Diameter | 3.60mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 2.00mm | ||
| Outer Diameter (mm) | 7.60±0.2mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Estimate weight | 97km/kg | ||
| Max conductor resistance DC 20℃ | 3.39Ω/km | ||
