SYEV-0-1.5/49-S
New energy vehicle cable
Description
Description
| Shoayer Part Number | SYEV-0-1.5/49-S | ||
| Rated Voltage | 1500V | ||
| Rated Temperature | ﹣40℃～﹢150℃ | ||
| Conductor | Material | Annealed copper | |
| SQMM | 1.5mm² | ||
| Composition | No.* AWG | 49/32AWG | |
| No.* mm | 49/0.20mm | ||
| Diameter | 1.60mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 1.20mm | ||
| Outer Diameter (mm) |
4.00±0.1mm | ||
| Color | Orange, Red, Black | ||
| Package | 200m/Roll | ||
| Estimate weight | 28km/kg | ||
| Rated current | 13.85A | ||
| Max conductor resistance DC 20℃ | 12.7Ω/km | ||
