SYEVP-0-2.0/64-S
New energy vehicle shielded cable
Description
Description
| Shoayer Part Number | SYEVP-0-2.0/64-S | ||
| Rated Voltage | 1500V | ||
| Rated Temperature | ﹣40℃～﹢150℃ | ||
| Conductor | Material | Annealed copper | |
| SQMM | 2.0mm² | ||
| Composition | No.* AWG | 64/32AWG | |
| No.* mm | 64/0.20mm | ||
| Diameter | 1.85mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 0.70mm | ||
| Shieded | Material | Tinner plated copper | |
| Composition | 16/4/0.12 | ||
| Density | ≥85% | ||
| Tape | Al-mylar | ||
| Jacket | Material | Silicone rubber | |
| Thickness | 0.70mm | ||
| Outer Diameter (mm) |
5.10±0.2mm | ||
| Color | Orange, Red, Black | ||
| Package | 200m/Roll | ||
| Rated current | 18.09A | ||
| Max conductor resistance DC 20℃ | 9.42Ω/km | ||
