Description
| Shoayer Part Number | SYM16878/11-2-14/19 | ||
| Rated Voltage | 600V | ||
| Rated Temperature | ﹣55℃～﹢200℃ | ||
| Conductor | Material | Silver plated copper | |
| AWG | 14AWG | ||
| Composition | No.*AWG | 29/27AWG | |
| No.* mm | 19/0.36mm | ||
| Diameter | 1.70mm | ||
| Insulation | Material | FEP (Fluorinated ethylene propylene) | |
| Thickness | 0.25mm | ||
| Outer Diameter (mm) |
2.20±0.1mm | ||
| Color | Optional | ||
| Package | 305m/roll | ||
| Estimate weight | 21.31km/kg | ||
| Rated current | 18.69A | ||
| Max conductor resistance DC 20℃ | 8.67Ω/km | ||
