SYYGZP-1-3×4.0/56
YGZP 300V 200℃ Multi-core Silicone Rubber Shielded Cable
Description
Description
| Shoayer Part Number | SYYGZP-1-3×4.0/56 | ||
| Rated Voltage | 300/500V | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 3x4mm² | ||
| Composition (No.* mm) | 56/0.30mm | ||
| Diameter | 2.70mm | ||
| Insulation | Material | Silicone rubber | |
| Thickness | 0.70mm | ||
| Diameter | 4.10mm | ||
| Shieded | Tinner plated copper | ||
| Jacket | Material | Silicone rubber | |
| Thickness | 1.70mm | ||
| Average Outer Diameter (mm) | 12.80±1.5mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Max conductor resistance DC 20℃ | 5.09Ω/km | ||
