SYYGZPF-1-2×1.0/19
YGZPF 300V 200℃ FEP Insulation Silicone Rubber Jacket Shield Cable
Description
Description
| Shoayer Part Number | SYYGZPF-1-2×1.0/19 | ||
| Rated Voltage | 300/500V | ||
| Rated Temperature | ﹣60℃～﹢200℃ | ||
| Conductor | Material | Tinner plated copper | |
| SQMM | 2x1mm² | ||
| Composition (No.* mm) | 19/0.26mm | ||
| Diameter | 1.30mm | ||
| Insulation | Material | FEP(Fluorinated ethylene-propylene) | |
| Thickness | 0.25mm | ||
| Diameter | 1.80mm | ||
| Shielded | Tinner plated copper | ||
| Jacket | Material | Silicone rubber | |
| Thickness | 1.20mm | ||
| Average Outer Diameter (mm) | 6.60±0.1mm | ||
| Color | Optional | ||
| Package | 100m/roll | ||
| Max conductor resistance DC 20℃ | 20.4Ω/km | ||
